Attributes
| Gtin | 5702422062653 |
|---|
Description
Inlet connection type: Solder, ODF, Outlet connection type: Solder, ODF, Direction: Angleway, Packing format: Multi pack
Specifications
| Quantity | Units of measure |
|---|---|
| Gross weight | 1.351 Kilogram |
| Net weight | 1.309 Kilogram |
| Volume | 3.24 Liter |
| EAN | 5702422062653 |
| Type | NRVH 35s |
| Product group | Check valves |
| Product Name Description | Check Valve |
| Approval | C UL US LISTEDCEEAC |
| Body material | Brass |
| Category | I |
| CE evaluated | Yes |
| China RoHS compliance | Yes with exemptions |
| Connection material | Copper |
| Connection notes | Oversize |
| Contains batteries | No |
| Cv value [gal/min] | 33.52 gal/min |
| Design | Piston |
| Direction | Angleway |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(c) |
| Flow direction | Single-flow |
| Flow direction indicator | Embossed 1-way arrow |
| Fluid Group | 2 |
| Inlet connection type | Solder, ODF |
| Inlet size [mm] | 42 mm |
| Kv value [m³/h] | 29 m³/h |
| Lubricants compatibility | Oilfree applications |
| Max. Working Pressure [bar] | 46 bar |
| Max. Working Pressure [psig] | 667 psig |
| Min. Pressure drop [bar] | 0.3 bar |
| Min. Pressure drop [psi] | 4.3 psi |
| Oil free refrigerants | R1234ze(E)R134aR513AR515B |
| Outlet connection type | Solder, ODF |
| Outlet size [mm] | 42 mm |
| Packing format | Multi pack |
| Quantity per packing format | 6 pc |
| Rated cap cond, Hot gas [IMP] | tcond=86 °Ftdisc=176 °Ftevap=14 °Fthotgas=140 °Ftsub=9 °F |
| Rated cap cond, Hot gas [SI] | tcond=30 °Ctdisc=80 °Ctevap=-10 °Cthotgas=60 °Ctsub=5K |
| Rated cap cond, Liq. cap [IMP] | tcond=86 °Ftevap=14 °Ftsub=9 °F |
| Rated cap cond, Liq. cap [SI] | tcond=30 °Ctevap=-10 °Ctsub=5K |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Refrigerants | R1233zd(E)R1234yfR1234ze(E)R1270R134aR170R22/R407CR290R32R404A/R507AR407AR407FR407HR410AR448AR449AR449BR450AR452AR452BR454AR454BR454CR455AR513AR515BR516AR600R600aRead more |
| SCIP dossier no. | 887a6675-66a4-4d55-a5bb-6b2ee1a517ab |
| SCIP dossier product name | NRV V1 22s -35s |
| Temperature range [°C] [Max] | 140 °C |
| Temperature range [°C] [Min] | -50 °C |
| Temperature range [°F] [Max] | 285 °F |
| Temperature range [°F] [Min] | -58 °F |
| UL approval file name | REFRIGERANT VALVE 53R0 |
| UL approved refrigerants | R1233zd(E)R1234yfR1234ze(E)R1270R134aR170R22R290R32R404AR407AR407CR407FR407HR410AR448AR449AR449BR450AR452AR452BR454AR454BR454CR455AR507AR513AR515BR516AR600R600aRead more |
| UL evaluated | Yes |
| Proposition 65 | WARNING: Cancer and Reproductive Harmwww.p65warnings.ca.gov |
| Visuals | Document Category |
