Danfoss product

AB-QM ANSI, 1½", With test plugs, External thread NPT

Scraped SKU: 003Z0780 2026-06-14 00:05:23

Attributes

Gtin5710104034652

Description

AB-QM 1½", with test plugs, pressure independent balancing and control valve

Specifications

QuantityUnits of measure
Gross weight7.04 Kilogram
Net weight6.934 Kilogram
Volume18.309 Liter
EAN5710104034652
TypeAB-QM ANSI
Product groupPressure independent balancing and control valves
Actuator connectionM30 x 1.5
China RoHS complianceOut of scope
Connection typesExternal thread NPT
Contains batteriesNo
DescriptionAB-QM 1½", with test plugs, pressure independent balancing and control valve
Differential pressure range [psi] [Max]60 psi
Differential pressure range [psi] [Min]4 psi
EU RoHS complianceYes with exemptions
EU RoHS exemption clause6(c)
Flow [gpm] [Max]33 gal/min
Flow nominal [m³/h]0 m³/h
Media temperature [°F] [Max]250 °F
Media temperature [°F] [Min]15 °F
REACH Candidate List substancesLead (CAS no. 7439-92-1)
Static pressure [psi] [Max]250 psi
Stroke [mm]10 mm
Test plugsWith test plugs
Valve body materialDuctile iron (EN-GJL-250)
Valve size1½"
Proposition 65WARNING: Cancer and Reproductive Harmwww.p65warnings.ca.gov
