Attributes
| Gtin | 5714279001631 |
|---|
Description
RLV-KB lockshield valve 1/2" straight
Specifications
| Quantity | Units of measure |
|---|---|
| Gross weight | 0.364 Kilogram |
| Net weight | 0.34 Kilogram |
| Volume | 0.168 Liter |
| EAN | 5714279001631 |
| Type | RLV-KB |
| Product group | H-piece valves |
| Application | 2-pipe system |
| CE evaluated | No |
| China RoHS compliance | Out of scope |
| Connection to radiator | G 1/2 |
| Connection to system | G 3/4 |
| Contains batteries | No |
| Description | RLV-KB lockshield valve 1/2" straight |
| Design | Straight |
| Distance center to center [mm] | 50 mm |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(c) |
| Flow temperature [°C] [Max] | 120 °C |
| Kvs values [m³/h] | 1.4 m³/h |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| SCIP dossier no. | fbd1f60c-e1ad-4d7e-b8fc-86136ff14cb2 |
| SCIP dossier product name | RLV-KB 1/2" H-piece |
| Surface | Nickel plated |
| Test pressure [bar] | 16 bar |
| UL evaluated | No |
| Valve size | 15 |
| Working pressure [bar] [Max] | 10 bar |
| Proposition 65 | WARNING: Cancer and Reproductive Harmwww.p65warnings.ca.gov |
| Visuals | Document Category |
